Shoe and Leather cutting Click die steel rule BE BD TE AE 32x2.0 , 19x2.0mm
Specifications
flexible in body for bending to different shape
used in leather (shoe) and fabric line
We provide click die steel in different size and different edge type.
Edge type: BD, BE, TE, AE, etc.
Size:
19x2.0
32x2.0
32x2.5
50x2.5, etc.
| Rule die steel | |||||||||||
| TYPE OF KNIFE | SIZE(mm) | APPLICABLE TO | |||||||||
|
19*2.0 32*3.5 40*3.5 | l Leatheroid,genuine leather shoe | |||||||||
| 19*2.5 32*4.0 40*4.0 | l Genuine leather furniture,handbag,suitcase | ||||||||||
| 20*3.0 36*2.0 43*2.5 | l Glove | ||||||||||
| 20*2.0 36*2.5 43*3.0 | l Genuine shoe leather | ||||||||||
| 30*3.0 36*2.7 43*3.5 | l Bootlace of genuine shoe leather | ||||||||||
| 32*3.0 36*3.0 5.0*2.5 | l Hardboard,fiberboard | ||||||||||
| 32*3.0 36*3.5 5.0*3.0 | l Aerated plastics | ||||||||||
| 30*3.0 36*4.0 5.0*4.0 | l Multilayer paper sole | ||||||||||
| 32*3.0 40*2.5 | l Middle sole | ||||||||||
| 32*2.7 40*3.0 | |||||||||||
| |
19*2.0 20*2.0 | l Leatheroid,genuine leather shoe | |||||||||
| 19*2.5 32*2.0 | l Genuine shoe leather | ||||||||||
|
19*2.0 | l Fiber ligament,wet ligament | |||||||||
| 19*2.5 | l Bootlace of genuine shoe leather,glove | ||||||||||
| 32*2.0 | l Genuine leathefurniture,handbag,suitcase | ||||||||||
| 36*2.5 | l Bootlace,flakeleather,fiberglass filling piece | ||||||||||
| l Rubberring,hardenorsoft monolayer rubber board | |||||||||||
| l Rubber,forming latex,aponge rubber | |||||||||||
| l Silk(a few layers<1mm) | |||||||||||
| l Monolayer rubbing paper | |||||||||||
| |
19*2.0 20*2.0 | l Leatheroid,genuine leather shoe | |||||||||
| 19*2.5 32*2.0 | l Genuine shoe leather | ||||||||||
|
32*2.0 40*2.5 | l Autocar control board and panel boar,tissue | |||||||||
| 32*2.5 40*3.0 | l Bamping material,deadening material of machine | ||||||||||
| 32*3.0 | l Cardboard,cork | ||||||||||
| l Fiberglass ski,fiberglass net cloth | |||||||||||
| l Aluminum foil made of fiberglass,fabric | |||||||||||
| l Horniness fiberboard,fiberboard,veneer(less4mm) | |||||||||||
| l Multilayer plastic foil | |||||||||||
| l Plush toy,weaving glove,liner | |||||||||||
| l Silk(multilayer) | |||||||||||
|
32*2.0 40*3.0 | l Autocar fabric | |||||||||
| 32*2.5 50*2.5 | l Autocar panel board | ||||||||||
| 32*3.0 50*3.0 | l Polyester fiber fabric | ||||||||||
| 40*2.5 | |||||||||||
|
32*2.0 | l Insole veneer | |||||||||
| 32*2.5 | l (4mm more) | ||||||||||
| 32*3.0 | |||||||||||
-
