Cnc Laser Cutting Machine / Medium Power Co2 Laser Engraving Machine 80w 100w 150w

Cnc Laser Cutting Machine / Medium Power Co2 Laser Engraving Machine 80w 100w 150w

เครื่องแกะสลักเลเซอร์

เครื่องตัดเลเซอร์

เครื่องแกะสลักเลเซอร์ 100w Co2

Place of Origin:

China

ชื่อแบรนด์:

Promega

ได้รับการรับรอง:

CE

Model Number:

Pro-LCM-80/100/150

ติดต่อเรา

ขอใบเสนอราคา
รายละเอียดสินค้า
สภาพ:
ใหม่
พลังเลเซอร์:
80~150 วัตต์
พื้นที่ทำงาน:
900mmx600mm
ความเร็วในการเคลื่อนที่:
0~50mm/s
ขนาดบรรจุ:
1535x1350x1250
น้ำหนักรวม:
360kg
เงื่อนไขการชำระเงินและการจัดส่ง
Minimum Order Quantity
one set
ราคา
USD 2000 ~ 3500 per set
Packaging Details
In wood case
Delivery Time
3 ~ 5 working days
Payment Terms
L/C, T/T
Supply Ability
10 sets per week
รายละเอียดสินค้า

Medium Power CO2 Laser Engraving Machine Cnc Laser Cutting Machine 80W 100W 150W

Applicable Material



This machine can be usd to cut cloth,leather,wool,fur,acrylic,plexiglass,wooden board,plastic,resin,rubber,bamboo product,resin and other non-metal materials. According to different needs, customers can choose 80 watt, 100 watt and 150watt machine.







Adavantage



The machine is suitable for garment,leather,package and printing,advertisement decoration,building upholster,art gift,computer embroidery,paper product,acrylic board of plastic,middle density board etc.non-metal sheet precision cutting and other industries.



Cnc Laser Cutting Machine / Medium Power Co2 Laser Engraving Machine 80w 100w 150w 0



Cnc Laser Cutting Machine / Medium Power Co2 Laser Engraving Machine 80w 100w 150w 1



Cnc Laser Cutting Machine / Medium Power Co2 Laser Engraving Machine 80w 100w 150w 2



Technical Parameters



 Laser Power

 50-150W(optional)

 Laser Type

 hermetic Co2 glass tube

 Power Supply

 AC220±10% 50HZ/AC 110±10% 60HZ

 Working Area

 900mm×600mm

 Max Moving Speed

 0---50mm/s

 Worktable

 honeycomb worktable/up&down worktable/aluminium knife(optional)

 Locating Precision

 <0.01mm

 Min Shaping Character

 character:3×3mm,letter:2×2mm

 Operating Temperature

 5℃---35℃

 Resolution Ratio

 ≤4500dpi

 Control Configuration

 DSP

 DataTransfer Interface

 USB(offline)

 Svstem Environment

 WINDOWS 2000/WINDOWS XP/Vista/win7

 Cooling Way

 water cooling and protection system

 Graphic Format Supported

 the files which CoreDraw,photoshop,AutoCAD can identify(BMP,GIF,JPEG,PCX,TGA,TIFF,PLT,CDR,DMG,DXF,PAT,CDT,CLK,DEX,

CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX)

 Compatible software

 CorelDraw,AutoCAD

 Cutting Thickness

 0---20mm(depends on different materials)

 Color Separation

 separation of cutting up to 256 colors

 Sloping Engraving

 yes,slope can be designed discretionarily

 Cuts off the Water Supply the Protection

 yes

 Machine Dimension

1535*1200*1025 mm

 Package Dimension

 1700*1350*1250 mm

 New Weight

 280kg

 Gross Weight

 360kg

 Optional Parts

 high-grade cooling system/imported focus lens/dobble-head/cylinder rotary attachment/irregular rotary attachment
